Request a quote on stock# 5508| Specification | Description |
|---|---|
| Spindle Diameter | 4.3" |
| Table Working Surface | 49.2" x 43.2" |
| Spindle Taper | #50 |
| Spindle Drive Motor | 10 HP |
| Spindle Speeds | 8 - 1000 RPM |
| Table Load Capacity | 6613 LBS |
| X Axis Travel | 62.9" |
| Y Axis Travel | 47.2" |
| Z Axis Travel | 55.1" |
| W Axis Travel (Quill) | 23.6" |
| Approximate Machine Weight | 39,700 LBS |
