HAAS ST-10Y; 2015; Milling/Y Axis Turning Center

HAAS ST-10Y; 2015; Milling/Y Axis Turning Center

Age: 2015

Stock Number: 5784

                            View a video of HAAS ST-10Y; 2015; Milling/Y Axis Turning Center
Click to view larger photo

Request A Quote On Our Stock Number: 5784 HAAS ST-10Y; 2015; Milling/Y Axis Turning CenterRequest a quote on stock# 5784
SpecificationDescription
Maximum Swing16.5"
Maximum Cutting Diameter12"
Maximum Cutting Length16"
Bar Capacity1.75"
X Axis Travel7.9"
Y Axis Travel+/- 2.0"
Z Axis Travel16"
Rapid Traverse Rate (X & Y)472 IPM
Rapid Traverse Rate ( Z )1200 IPM
Spindle NoseA2-5
Spindle Motor15 HP
Spindle Speed6000 RPM
C Axis Positioning0.02 deg
Turret Positions12
Live Tooling Speed4000 RPM
Approximate Machine Weight7900 LBS

Equipped With:
Haas CNC Control
Manual Tailstock with Hydraulic Quill
Belt Type Chip Conveyor
High Pressure Coolant / 300 PSI
Auto Tool Presetter
Parts Catcher
