KIWA KMH300-F005; 2018; 12.6 Pallets Horizontal Machining Center

KIWA KMH300-F005; 2018; 12.6" Pallets Horizontal Machining Center

Age: 2018

Stock Number: 5792


Click to view larger photo

Request A Quote On Our Stock Number: 5792 KIWA KMH300-F005; 2018; 12.6 Pallets Horizontal Machining CenterRequest a quote on stock# 5792
SpecificationDescription
Pallet Size12.6" x 12.6"
Number of Pallets2
X Axis Travel18.1"
Y Axis Travel18.1"
Z Axis Travel13.7"
Table Indexing0.001 deg
Spindle Center to Worktable Surface2.36" - 20.4"
Spindle Nose to Work Table Center2.36" - 16.1"
Maximum Work Table Load550 LBS
Maximum Work Piece Height18.7"
Spindle Speed15,000 RPM
Spindle TaperBig Plus BT#30
Tool Storage30 ATC
Rapid Traverse Rate (X,Y,Z)1968 IPM
Spindle Motor15 HP 30 Min
Drive MethodDirect Drive
Approximate Machine Weight13,500 LBS



Equipped With:
Fanuc 0i-MF
Chip Conveyor - Scrapper Type
High Pressure Coolant Prep - No Pump
Coolant Through Ball Screws
Dual Internal Augers
Spindle Oil Cooling

MULTIPLE UNITS AVAILABLE - Contct us for included options details on each
