Request a quote on stock# 5787| Specification | Description |
|---|---|
| Work Table | 25.5" x 13.7" |
| X Axis Travel | 14.9" |
| Y Axis Travel | 11.0" |
| Back Slide | 9" |
| Z Axis Travel | 7.2" |
| Open Height | 3.3" - 19.6" |
| Work Tank | 39.3" x 23.6" x 12.9 H |
| Maximum Oil Level | 11.0" |
| Dielectric Reservoir Capacity | 75 Gal |
| Weigth Capacity Electrode on Platen | 220 LBS |
| Weight Capacity Work Piece | 2,200 LBS |
| Maximum Peak Current | 100 A |
| On Off Time | 1 to 4000 us |
| Maximum Rotational Speed C Axis | 35 RPM |
| Floor Space | 96" x 63" x 74" H |
| Approximate Machine Weigth | 4180 LBS |
